110v 220v High Accuracy Checkweigher Skin Care System For Skin Care Factory
Contact Person : SICI AUTO
Phone Number : 18921338139
WhatsApp : +8618921338139
| Minimum Order Quantity : | 1 set | Packaging Details : | Wooden Case |
|---|---|---|---|
| Delivery Time : | 30 work days | Payment Terms : | T/T |
| Supply Ability : | 50 set/ month |
| Place of Origin: | Wuxi | Brand Name: | SICI AUTO |
|---|---|---|---|
| Certification: | CE | Model Number: | XQ-CZ220 |
|
Detail Information |
|||
| Name: | Cigarette Box High Accuracy Checkweigher | Accuracy: | ±0.2-0.5g |
|---|---|---|---|
| Speed: | 100pcs/min | Minimum Scale: | 0.1g |
| Available Product Size: | 300*220*3-200mm | Removing Type: | Push Plate/flipper/drop Out |
| Voltage: | 110/220v | Power: | 100w |
| Data Output: | USB | Optional: | Printing Data In Real Time |
| Application: | Cosmetics, Skin Care, Food | ||
| High Light: | push plate High Accuracy Checkweigher,Cigarette Box High Accuracy Checkweigher,100w high speed checkweigher |
||
Product Description
Cigarette Box High Accuracy Checkweigher with Push plate/Flipper/Drop out Reject System
Product Introduction of Checkweigher
A checkweigher is an automatic or manual machine for checking the weight of packaged commodities. It is normally found at the offgoing end of a production process and is used to ensure that the weight of a pack of the commodity is within specified limits. Any packs that are outside the tolerance are taken out of line automatically.
Automatic checkweigher is widely used in food, agriculture, fishery, chemical, light industry, medicine, building materials, machinery, electronics, energy, textile, packaging, health care products, cosmetics and other industries.
Technical Parameter
| Model | XQ-CZ220 | |||||||||
| Weighing Scope | 5-1500g | |||||||||
| Weighing Accuracy | ±0.2-0.5g (depends on product) | |||||||||
| Minimum Scale | 0.1g | |||||||||
| Max. Speed | Max 100pcs/min | |||||||||
| Product Limit | L | 300mm | ||||||||
| W | 220mm | |||||||||
| H | 3-200mm | |||||||||
| Operating Mode | Touch screen | |||||||||
| Operation Interface | 7 inch touch screen | |||||||||
| Removing Type | push plate/flipper/drop out | |||||||||
| The Height from Ground to Belt | 750±50mm (can be customized) | |||||||||
| Machine Structure | Stainless steel (SUS304) | |||||||||
| Working Voltage | AC110V/220V 50-60HZ | |||||||||
| Power | About 100w | |||||||||
| Working Table Dimension | 407mmX220mm | |||||||||
| Machine Weight | About 80kg | |||||||||
| Optional | alarm light, RS485 output port, | |||||||||
| Remark | The properties and environment of the tested products are different, and the detection speed and accuracy are also different. The actual test is taken as the standard. | |||||||||
Checkweigher Features
XQ-CZ220 Cigarette Box High Accuracy Checkweigher with Push plate/Flipper/Drop out Reject System
- Large color LCD touch screen interface, simple operation and intuitive display.
- Support customized multi-language, the default is Chinese and English.
- Test data of 100 kinds of products can be set and stored to facilitate user switching.
- Automatic photoelectric detection with empty bag, adjustable conveyor belt speed, automatic learning function.
- Password protection is set for parameter, only for management personnel.
- Automatic zero tracking system to ensure reliable detection data.
- Independent research and development of single-chip microcomputer system, unique filtering algorithm, to ensure the stability of the system.
- Simple mechanical structure, buckle conveyor belt, easy to disassemble, clean and maintain.
- Machine structure is made of stainless steel 304.
Samples
