110v 220v High Accuracy Checkweigher Skin Care System For Skin Care Factory
Contact Person : SICI AUTO
Phone Number : 18921338139
WhatsApp : +8618921338139
Minimum Order Quantity : | 1 set | Packaging Details : | Wooden Case |
---|---|---|---|
Delivery Time : | 30 work days | Payment Terms : | T/T |
Supply Ability : | 50 set/ month |
Place of Origin: | Wuxi | Brand Name: | SICI AUTO |
---|---|---|---|
Certification: | CE | Model Number: | XQ-CZ450B |
Detail Information |
|||
Name: | Frozen Chicken High Accuracy Checkweigher | Accuracy: | ±1-3g |
---|---|---|---|
Speed: | 120pcs/min | Minimum Scale: | 1g |
Available Product Size: | 400*300*5-400mm | Removing Type: | Flipper |
Voltage: | 220v 50Hz | Power: | 1.5kw |
Data Output: | USB | Optional: | Printing Data In Real Time, Alarm Light, RS485 Output Port |
Application: | Perfume, Medicine, Stationery | ||
High Light: | Flipper Reject checkweigher machine,Frozen Chicken checkweigher machine,1.5kw industrial checkweigher |
Product Description
Frozen Chicken Automatic High Accuracy Checkweigher with Flipper Reject System
Product Introduction of Checkweigher
A checkweigher is an automatic or manual machine for checking the weight of packaged commodities. It is normally found at the offgoing end of a production process and is used to ensure that the weight of a pack of the commodity is within specified limits. Any packs that are outside the tolerance are taken out of line automatically.
It's used for automatic weight detection, upper and lower limit discrimination or weight classification and selection on various automatic assembly lines and logistics transmission systems, as well as for the detection of more or less parts after product packaging.
Technical Parameter
Model | XQ-CZ450B | |||||||||
Weighing Scope | 5g-3000g | |||||||||
Weighing Accuracy | ±1g (depends on product and speed) | |||||||||
Max. Speed | Max 120pcs/min | |||||||||
Product Limit | L | 400mm | ||||||||
W | 300mm | |||||||||
H | 5-400mm | |||||||||
Operating Mode | Touch screen | |||||||||
Operation Interface | 7 inch touch screen | |||||||||
Removing Type | flipping rejector by motor driven | |||||||||
The Height from Ground to Belt | 750±50mm (can be customized) | |||||||||
Machine Structure | Stainless steel (SUS304) | |||||||||
Working Voltage | 220V 50-60HZ | |||||||||
Power | About 1.5KW | |||||||||
Working Table Dimension | 700mmX300mm | |||||||||
Machine Weight | About 120kg | |||||||||
Optional | alarm light, RS485 output port, | |||||||||
Remark | The properties and environment of the tested products are different, and the detection speed and accuracy are also different. The actual test is taken as the standard. |
Checkweigher Features
XQ-CZ450B Frozen Chicken Automatic High Accuracy Checkweigher with Flipper Reject System
- User-friendly operating system.
- Chinese-English interface.
- Weight of products can be compensated.
- Product qualification ratio can be showed in line graphs and bar charts.
- Independent research and development of single-chip microcomputer system, unique filtering algorithm, to ensure the stability of the system.
