110v 220v High Accuracy Checkweigher Skin Care System For Skin Care Factory
Contact Person : SICI AUTO
Phone Number : 18921338139
WhatsApp : +8618921338139
| Minimum Order Quantity : | 1 set | Packaging Details : | Wooden Case |
|---|---|---|---|
| Delivery Time : | 30 work days | Payment Terms : | T/T |
| Supply Ability : | 50 set/ month |
| Place of Origin: | Wuxi | Brand Name: | SICI AUTO |
|---|---|---|---|
| Certification: | CE | Model Number: | XQ-CZ100 |
|
Detail Information |
|||
| Name: | High Accuracy Checkweigher For Food | Accuracy: | ±0.05g |
|---|---|---|---|
| Speed: | 200pcs/min | Minimum Scale: | 0.01g |
| Available Product Size: | 100*100*2-150mm | Removing Type: | Blow Away |
| Voltage: | 110/220v | Power: | 100w |
| Data Output: | USB | Optional: | Printing Data In Real Time |
| Application: | Candy, Biscuit, Chocolate | ||
| High Light: | Biscuit Bag food checkweigher,200pcs min food checkweigher,food in motion checkweigher |
||
Product Description
Small Bag High Accuracy Checkweigher 200pcs/min for Food
Automatic Biscuit Bag High Accuracy Checkweigher 200pcs/min for Food
Checkweigher Introduction
A checkweigher is an automatic machine for checking the weight of packaged products. Any packs that are outside the tolerance are taken out of line automatically. Checkweighers are widly used in cleanrooms, mints (rolls of coins), dry atmosphere environments, wet environments, produce barns, food processing, drug processing, cosmetics filling, etc.
Technical Parameter
| Model | XQ-CZ100 | |||||||||
| Weighing Scope | 2-300g | |||||||||
| Weighing Accuracy | ±0.05g (depends on product) | |||||||||
| Minimum Scale | 0.01g | |||||||||
| Max. Speed | Max 200pcs/min | |||||||||
| Product Limit | L | 100mm | ||||||||
| W | 100mm | |||||||||
| H | 2-150mm | |||||||||
| Operating Mode | Touch screen | |||||||||
| Operation Interface | 7 inch touch screen | |||||||||
| Removing Type | Blow away | |||||||||
| The Height from Ground to Belt | 750±50mm (can be customized) | |||||||||
| Machine Structure | Stainless steel (SUS304) | |||||||||
| Working Voltage | AC110V/220V 50-60HZ | |||||||||
| Power | About 100w | |||||||||
| Working Table Dimension | 200mmX100mm | |||||||||
| Machine Weight | About 60kg | |||||||||
| Optional | alarm light, RS485 output port, | |||||||||
| Remark | The properties and environment of the tested products are different, and the detection speed and accuracy are also different. The actual test is taken as the standard. | |||||||||
Checkweigher Features
Model: XQ-CZ100 Automatic High Accuracy Checkweigher with reject system
- Test data of 100 kinds of products can be set and stored to facilitate user switching.
- Automatic photoelectric detection with empty bag, adjustable conveyor belt speed, automatic learning function.
- Password protection is set for parameter, only for management personnel.
- Automatic zero tracking system to ensure reliable detection data.
