70-100pcs/Min Toothpaste Cartoning Machine Tube Horizontal Cartoner Machine
Contact Person : SICI AUTO
Phone Number : 18921338139
WhatsApp : +8618921338139
| Minimum Order Quantity : | 1 set | Packaging Details : | Wooden Case |
|---|---|---|---|
| Delivery Time : | 50 work days | Payment Terms : | T/T |
| Supply Ability : | 30 set/ two months |
| Place of Origin: | Wuxi | Brand Name: | SICI AUTO |
|---|---|---|---|
| Certification: | CE | Model Number: | XQ-ZH100 |
|
Detail Information |
|||
| Name: | Bottle Cartoner Packaging Machine | Feeding Mode: | Automatic |
|---|---|---|---|
| Available Product: | Bottle | Sealing Type: | Tuck In |
| Speed: | 30-100pcs/min | Power: | 1.5kw |
| Voltage: | 220/380v | Available Carton Size: | (70-200)mm×(35-120)mm×(14-70)mm |
| Optional: | Automatic Feeding Device, Ink-jet Printer | Application: | Lotion, Tablet, Capsule, Chewing Gum |
| High Light: | cosmetic Cartoner Packaging Machine,bottle Cartoner Packaging Machine,100pcs min box packing machine |
||
Product Description
Automatic Bottle Carton Packing Machine Cartoner Packaging Machine for Medical Cosmetics with Automatic Feeding Device
Cartoner Packaging Machine Introduction
This machine is suitable for automatic feeding and packing of bottle (round bottle, square bottle). On-line automatic bottle finishing and conveying, manual folding (1 to 4 times folding) and transmission, manual detection, carton suction forming and transmission, material into the box, embossing batch number, paper tongue packaging at both ends of the carton (also applicable to hot melt adhesive), missing material removal and finished product output and other whole processes are automatic completion.
Technical Parameter
| Model | XQ-ZH100 | |
|
Box |
Quality Requirement | 300-450g/m² |
| Dimension Range | (70-200)mm×(35-120)mm×(14-70)mm | |
| Production Capacity | 30-100pcs / min | |
| Total Power | 1.5kw | |
| Working Voltage | 220V/380V 50Hz | |
| Instruction Leaflet Size | Quality Requirement | 60-70g/m² |
| Unfolded Dimension | (80-250)mm×(90-170)mm | |
| Folded Dimension | 1-4 folded | |
| Compressed Air | Working Pressure | ≥0.5Mpa |
| Air Consumption | 120-160L/min | |
| Machine Weight | 1300kg | |
| Machine Dimensions | 4300mm×1300mm×1900mm | |
Machine Principle
Cartoning Machine Features
Model:XQ-ZH100 Automatic Bottle Carton Packing Machine Cartoner Packaging Machine for Medical Cosmetics with Automatic Feeding Device
| Man-machine interface operating system. |
| Mechanical overload automatic shutdown. |
| Automatic elimination of the lack of packaging and instructions of the carton. |
| Fault display, alarm and finished product count. |
| Stable performance, easy to understand operation. |
| PLC automatic control system, frequency conversion speed control, electrical components are all international famous brands. |
Samples
