Bottle Can Tray Shrink Wrapping Machine Sleeve Type Automatic
Contact Person : SICI AUTO
Phone Number : 18921338139
WhatsApp : +8618921338139
Minimum Order Quantity : | 1 set | Packaging Details : | Wooden Case |
---|---|---|---|
Delivery Time : | 30-45 work days | Payment Terms : | T/T |
Supply Ability : | 100 set/ month |
Place of Origin: | Wuxi,China | Brand Name: | SICI AUTO |
---|---|---|---|
Certification: | CE | Model Number: | XQ-ZWG-590 |
Detail Information |
|||
Name: | Flow Cut Shrink Wrapping Machine | Automatic Grade: | Automatic |
---|---|---|---|
Available Product: | Vegetables, Fruits, Tomatoes, Cucumbers, Etc. | Speed: | 30-150 Pcs/min |
Cut-seal Way: | Flow Cut | Cutter Driven Method: | Auto, Servo |
Shrink Wap Effect: | Full-closed | Shrink Film: | POF |
Function: | For Single Or Bundle Productg Shrink Wrap | Application: | Shink Wrapping For Vegetables, Fruits, Tomatoes, Cucumbers, Etc. |
High Light: | vegetable automatic shrink sleeve machine,30 PCS MIN automatic shrink sleeve machine,150 PCS MIN shrink machine tunnel |
Product Description
Vegetables Shrink Wrapping Packaging Machine / Speed 30-150PCS/MIN
Vegetable packaging machine is a heat shrinkable film automatic packaging machine, which is suitable for heat shrinkable automatic packaging of vegetables, garlic seedlings, fruits, tomatoes, cucumbers and other products..
Max Flim size | ≤590mm | ||||
Model | 120 | 150 | 180 | 210 | |
Packing size | L | L:60mm-320mm | L:100mm-450mm | L:150mm-530mm | L:180mm-600mm |
W | w:10mm-200mm | w:10mm-200mm | w:10mm-200mm | w:10mm-200mm | |
H | H:5mm-35mm | H:35mm-70mm | H:75mm-100mm | H:80mm-130mm | |
Packing speed | 30-150 pcs/min | 30-150 pcs/min | 30-135 pcs/min | 30-100 pcs/min | |
Flim type | POF | ||||
Power consumption | Flow-cut machine:4.5KW;Shrink tunnel:15.5KW | ||||
Power supply | Flow-cut machine:220V,50HZ/60HZ; Shrink tunnel:380V,50HZ/60HZ | ||||
Flow-cut machine | 5000x1170x1500mm | ||||
Shrink tunnel | 2600x600x1700mm | ||||
Weight | Flow-cut machine:1000KG | Shrink tunnel:600KG |
1. The machine can be packaged individually or in any group. It is a fully automatic heat shrinkable packaging machine designed for assembly line operations and mass packaging.
2. According to the specific conditions of the product, an automatic feeding system can be selected to realize unmanned operation of feeding materials, and various forms of conveyors can ensure that the materials will not move or roll.
3. The anti-cutting safety clutch device does not damage the packaging, so the overall efficiency is high.
4. After packaging, the sealing of the product is linear, and the steel pattern is clear and beautiful.
5. Bag length, speed and temperature can be adjusted individually, which is convenient and accurate.
6. The control unit is composed of servo motor and servo driver. The control precision is extremely high. The intelligent control system makes all parameters easy to set and accurate to lock; bag forming, cutting length, sealing temperature and other parameters can be locked more accurately.
7. The servo system replaces the traditional mechanical film feeding system, simplifies the mechanical structure, makes the operation of the packaging machine more stable, the daily maintenance is more convenient and simple, reduces the skill requirements for the operator, and also reduces the noise and noise of the machine operation. The failure rate is significantly reduced;
8. The use of variable frequency speed regulation reduces costs and improves cost performance;
9. The new type of vertical sealing heating can seal at low temperature and reduce the amount of hot film on parking.
