Condom Cellophane Automatic Overwrapping Machine Tear Tape Equipment
Contact Person : SICI AUTO
Phone Number : 18921338139
WhatsApp : +8618921338139
| Minimum Order Quantity : | 1 set | Packaging Details : | Wooden Case |
|---|---|---|---|
| Delivery Time : | 30 work days | Payment Terms : | T/T |
| Supply Ability : | 30 set/month |
| Place of Origin: | Wuxi | Brand Name: | SICI AUTO |
|---|---|---|---|
| Certification: | CE | Model Number: | XQ-SW350 |
|
Detail Information |
|||
| Name: | Automatic Overwrapping Machine For Cosmetics | Wrapping Mode: | Single Wrapping |
|---|---|---|---|
| Speed: | 20-55pcs/min | Available Box Dimension: | L50-300mm, W35-200mm, H20-100mm |
| Sealing Type: | Flat Sealing | Film Feeding Mode: | Servo Feeding/cam Feeding |
| Power: | 4kw | Voltage: | 220v |
| Optional: | Anti-static Bar, Ironing Machine | Application: | Condom, Rubber, Medicine |
| High Light: | 20 pcs min automatic cellophane wrapping machine,55 pcs min automatic cellophane wrapping machine,Cigarette overwrap packaging machine |
||
Product Description
Cigarette Box 20-55pcs/min Automatic Overwrapping Machine with Tear Tape
Product Introduction of Overwrapping Machine
Automatic Overwrapping Machine also called as cigarette wrapping machine, it's widely used for cigarette first and then extend to different industries. SICI AUTO developed XQ-SW350 has the features of large range packaging specifications, widely applies to medicine, food, health care products, stationery, commodity and video products industry. Automatic single packaging of varies box products, or assembly packaging of multi box. One machine can do flat sealing and spot sealing at the same time. You can switch these two sealing ways according to your packing requriements.
Technical Parameter
| Model | XQ-SW350 |
| Packing Size | L50-300mm, W35-200mm, H20-100mm |
| Production Capacity | 20-55 packs / min |
| Total Power | 4kw |
| Working Voltage | 220V |
| Air Consumption | 5-8L/min |
| Air Compressure | 0.4-0.8Mpa |
| Machine Weight | 750kg |
| Machine Dimensions | 2200 (mm) × 950 (mm) × 1800 (mm) |
| Conveyor Belt | 1500 (mm) ×300 (mm) × 900 (mm) |
|
Packaged Wooden Case Dimesnion/ Weight |
2350 (mm) ×1250 (mm) × 2250 (mm)/900kg |
Machine Principle
Overwrapping Machine Features
Model:XQ-SW350 Medicine Box Bundle Wrap Automatic Overwrapping Machine with Ironing Machine
| 1. Stainless steel 304 machine body and organic glass cover. |
| 2. Flexible size ranges and quick change over mould. |
| 3. GMP standard alumina working plate, flatting and smoothing. |
| 4. Tear tape, ink printer, box turning over and stacking are optional. |
| 5. Easy to change the moulds for different sizes! (within 15 miniutes) |
